Description
The INFiLED AMmk2 is a transparent outdoor LED display designed for rental and large-scale events. With 70% transparency, it delivers spectacular visuals without obscuring background scenery — ideal for music festivals, sports events, concerts, and architectural installations.
Featuring 8.33mm pixel pitch and 3,500 nits of brightness, the AMmk2 produces vivid, high-contrast imagery even in direct sunlight. The ultra-thin cabinet (55.4mm deep) supports curved configurations from -15° to +10°, enabling creative stage designs and immersive visual environments.
Key Features
- 8.33mm pixel pitch — optimized for large-format outdoor transparency
- 70% transparency — content display without blocking the view
- 3,500 nits brightness — exceptional outdoor visibility
- IP65 rated — fully weatherproof front and rear
- 1200 x 1200mm cabinet — fast, large-area deployment
- 15.5 kg per panel — lightweight for its size
- Curved screen support — adjustable -15° to +10°
- 3,840 Hz refresh rate — flicker-free on camera
- UL94 V0 flame retardant certification
Technical Specifications
| Pixel Pitch | 8.33mm |
| Physical Density | 14,400 pixels/m² |
| LED Arrangement | 3-in-1 SMD |
| Module Resolution (H/V) | 72 x 9 pixels |
| Module Dimensions | 600 x 75mm |
| Cabinet Resolution (H/V) | 144 x 144 pixels |
| Cabinet Dimensions | 1200 x 1200 x 55.4mm |
| Cabinet Weight | 15.5 kg (34.17 lb) |
| Brightness | 3,500 nits |
| Max Power Consumption | 660W per panel |
| Avg Power Consumption | 220W per panel |
| Viewing Angle (H/V) | 160° / 160° |
| Scan Rate | 1/4 |
| Power Source | 100-240V AC 50/60Hz |
| Operating Temperature | -20°C to +50°C |
| Refresh Rate | 3,840 Hz |
| IP Rating | IP65 |
| Transparency | 70% |
| Signal Input | DVI, HDMI, DP, SDI |
| Certifications | CE, FCC, ETL, RoHS |
