Brompton Tessera XD — Data Distribution Unit
The Brompton Tessera XD is the essential companion to the SX40 processor. It distributes processed video data to LED panels via Gigabit Ethernet, expanding the SX40’s output capacity for larger video walls. Each XD provides 12 additional output ports, and multiple XDs can be daisy-chained for massive installations.
The XD maintains Brompton’s frame-accurate processing pipeline and supports redundant data paths for mission-critical applications. It’s the standard distribution unit for touring, broadcast, and VP/XR stages running Brompton.
Key Features
- 12x Gigabit Ethernet outputs to receiver cards
- Expands SX40 processor capacity
- Redundant input for failover protection
- 1U rack mount — compact and tour-ready
- Daisy-chain multiple XDs for large walls
- Zero additional latency
- Hot-swappable in redundant configurations
Technical Specifications
| Inputs | 2x Gigabit Ethernet (primary + redundant) |
| Outputs | 12x Gigabit Ethernet |
| Latency | Zero additional |
| Redundancy | Dual input failover |
| Dimensions | 1U rack mount (19″) |
| Weight | 2.8 kg |
| Power | 30W |
Ideal Applications
- Large-format video walls (paired with SX40)
- Touring and festival LED systems
- Broadcast studios
- Virtual production LED volumes
- Any Brompton Tessera installation requiring additional outputs
