Description
High-output flyable cardioid subwoofer for the SL-Series. Three long-excursion 21-inch neodymium drivers in a 2-way bass-reflex design deliver massive low-frequency output with remarkable cardioid directional control. Extends GSL system bandwidth down to 30Hz.
Specifications:
– Type: Cardioid subwoofer (passive, flyable)
– Drivers: 3x 21″ long-excursion neodymium
– Frequency Response: 33Hz – 84Hz (-5dB standard); 30Hz – 65Hz (INFRA mode)
– Max SPL: 144dB (1m, free field, with D80)
– Modes: Cardioid, omni, end-fire
– Connectors: 1x NLT4 F
– Flying: Up to 14 units in flown arrays
– Enclosure: Marine plywood, touring-grade
– Dimensions: 1300mm W x 585mm H x 975mm D, 1100mm deep incl. wheels (51.2″ x 23″ x 38.4″; 43.3″ incl. wheels)
– Weight: 138 kg / 304 lbs
– Amplification: d&b D80 required (2-Way Active mode, two amplifier channels per cabinet)
– Compatible with GSL, KSL, and xSL systems
