Description
4-channel Class D amplifier with integrated DSP, color touchscreen, and network control. Powers up to 4 passive d&b loudspeakers with loudspeaker-specific processing including FIR/IIR EQ, delay, and limiting. Active Power Factor Correction for universal mains compatibility.
Specifications:
– Channels: 4
– Power Output: 4x 2,400W at 4 ohms / 4x 2,000W at 8 ohms (all channels driven)
– Max Output: 180V peak / 35A peak per channel
– Topology: Class D with switch-mode PSU and active PFC
– DSP: Integrated FIR/IIR loudspeaker processing
– Display: 4.3″ color TFT touchscreen
– Analog Inputs: 4x XLR (female, 3-pin)
– Digital Inputs: 2x AES3 pairs (44.1/48/96/192kHz)
– Speaker Outputs: 4x NL4 + 1x NL8
– Network: 2x RJ45 (1Gbit/100Mbit Ethernet), OCA
– Dante: Optional
– Power Input: powerCON TRUE1 TOP
– Mains: 100-127V / 208-240V, 50-60Hz (autosensing)
– Dimensions: 2U x 482.6mm W x 512mm D (19″ x 2U x 20.2″)
– Weight: 13.8 kg / 30.4 lbs
