Description
The Martin Audio ASF20071 Wind Up Pole is a professional crank-operated speaker pole designed for safely raising and lowering Martin Audio loudspeakers to the ideal listening height. Unlike standard tripod stands that require lifting speakers overhead, the wind-up mechanism lets you mount the speaker at ground level and smoothly crank it into position — safer, faster, and essential for heavier cabinets.
Key Features
- Wind-up crank mechanism — Raise and lower speakers with a hand crank instead of lifting overhead. Safer for heavy cabinets and faster for setup crews
- 35 kg (77 lb) load capacity — Supports Martin Audio CDD-LIVE, WPM, MLA Mini, DD6, and other compatible loudspeakers
- 605mm to 1,017mm height range — Adjustable from ~24″ to ~40″ above the subwoofer, placing speakers at optimal ear height for seated or standing audiences
- 35mm top fitting — Standard pole diameter fits all Martin Audio portable loudspeakers with 35mm top-hat receivers
- M20 threaded base — Threads directly into Martin Audio subwoofers (SX118, SXC118, SX218, DXF115, SXC115) for a rock-solid sub-sat configuration
- Push-button safety lock — Prevents accidental lowering once the speaker is at the desired height
- Rugged steel construction — Built for touring and daily rental use
- Lightweight — Only 3.93 kg (8.7 lbs) for easy transport
Technical Specifications
| Model | Martin Audio ASF20071 |
| Type | Wind-up crank speaker pole |
| Height Range | 605 – 1,017 mm (23.8″ – 40″) |
| Load Capacity | 35 kg (77 lbs) |
| Top Fitting | 35mm diameter |
| Base Fitting | M20 threaded |
| Construction | Steel, powder-coated black |
| Weight | 3.93 kg (8.7 lbs) |
| Safety | Push-button lock |
Included with Martin Audio speaker package rentals. Also available individually. Request a quote or call (718) 218-5941.
