Description
Professional 4K digital signage media player built for high-performance installations and interactive displays. Hardware-accelerated H.265, H.264, VP9, and AV1 decoding delivers striking 4K60p content. Dual video decode enables picture-in-picture or simultaneous content zones. Full HTML5/CSS/JavaScript rendering at 60fps powers rich interactive experiences with responsive multi-touch support. PoE+ eliminates the need for a separate power supply, simplifying installation. BrightSignOS provides purpose-built reliability with secure boot and encrypted storage.
Specifications:
– Video Output: HDMI 2.0a (4K60p)
– 4K Codecs: H.265/HEVC (8-bit 60p, 10-bit 30p), H.264/AVC (30p), VP9, AV1
– Full HD Codecs: H.265, H.264, VP9, MPEG-4 Part 2, MPEG-1/2
– Video Containers: MP4, MOV, MKV, WEBM, TS, AVI, MPG
– Video Decode: Dual simultaneous (Full HD)
– Video Rotation: Hardware-accelerated 4K
– Images: BMP, JPEG, PNG
– Audio: MP2, MP3, AAC, WAV, AC3 pass-through
– HTML5: CSS, JavaScript, SVG, WebGL (Chromium-based, 60fps)
– Ethernet: Gigabit with PoE+ (IEEE 802.3at)
– WiFi/Bluetooth: Optional via M.2 E Key WD-105 module
– USB: 1x USB-C (host, 5V/1A), 1x USB-A (5V/1A)
– Storage: Micro SD slot (tool-less cover) + optional M.2 NVMe SSD
– GPIO: 8x bidirectional (12-pin Phoenix connector)
– OS: BrightSignOS (secure boot, encrypted storage)
– Power: 12V/3A (locking connector) or PoE+
– Enclosure: Patented aluminum heat-dissipating design
– Dimensions: 8.07″ x 7.32″ x 0.76″ (205 x 186 x 19.2 mm)
– Weight: 1.3 lbs (0.59 kg)
– Operating Temp: 0°C—50°C (32°F—122°F)
– Warranty: 5-year standard
– Models: XD235 (Standard I/O), XD1035 (Expanded I/O)
