Description
The Allen & Heath SQ-5 is a compact yet powerful 48-channel digital mixer powered by the XCVI 96kHz FPGA engine, delivering class-leading audio quality with ultra-low latency under 0.7 ms. Its 16+1 motorized faders, 7-inch touchscreen, and built-in 32×32 USB audio interface make it a versatile workhorse for live sound, streaming, recording, and corporate AV. The SQ-5 fits in a standard 19-inch rack for easy transport.
Key Features
- 48 input channels with XCVI 96kHz FPGA processing
- 16+1 motorized faders with 7" capacitive touchscreen
- 12 stereo mixes + LR, 3 stereo matrix, 8 stereo FX engines
- Built-in 32×32 96kHz USB audio interface for multitrack recording
- SQ-Drive: record up to 32 channels direct to USB drive
Technical Specifications
| Spec | Value |
|---|---|
| Input Channels | 48 |
| Busses | 36 (12 stereo mix + LR + 3 stereo matrix) |
| FX Engines | 8 stereo with dedicated returns |
| Faders | 16+1 motorized |
| Preamps | 16+1 onboard |
| Latency | <0.7 ms |
| USB Interface | 32×32 at 96 kHz |
| Form Factor | 19" rack-mountable |
Available for rent from Ashley Systems in NYC. Same-day delivery across Manhattan, Brooklyn, and the tri-state area. Request a quote.
